PRODUCT PARAMETER
DIMENSIONS & WEIGHT
| Length x Width x Height (mm) | 1790mm x 800mm x 1090mm |
| Wheelbase (mm) | 1240mm |
| Seat Height (mm) | 820mm |
| Ground Clearance (mm) | 310mm |
| Net Weight (kg) | 80kg |
| Tire (Front & Rear) | 70/100-17, 90/100-14 |
| Fuel Capacity (L) | 5.5L |
| Engine Oil Capacity (L) | 1.1L |
POWER
| Engine | single-cylinder, 4-stroke, air-cooling, horizontal |
| Displacement (cc) | 119.6cc |
| Bore x Stroke (mm) | 52.4mm x 55.5mm |
| Compression Ratio | 9.3:1 |
| Maximum Power (kW/r/min) | 5.6kW / 8000r/min |
| Maximum Torque (N·m/rpm) | 8.5N·m / 5000rpm |
| Maximum Speed (km/h) | 85km/h |
| Ignition Type | CDI |
| Starter System | electric/kick |
| Battery Type | 12V 4Ah |
SUSPENSION
| Front Suspension | length 725mm tube ø33mm travel 182mm |
| Rear Suspension | length 295mm travel 68mm |
| Brake System | hydraulic disc brake |
